220V, 750W, 3000 RPM Servo Motor with Integrated Brake and Absolute Optical Encoder. Designed for precise motion control, this motor delivers reliable performance, high efficiency, and accurate positioning. Ideal for industrial automation applications requiring stable speed, strong holding capability, and precise feedback.
₹23,999.00
Downloads
Product Details
Specifications
AC Servo Motor
- Rated Voltage (V):220
- Rated Speed (RPM):3000
- Rated Torque (Nm):2.4
- Rated Output Power (W):750
- Rotor Inertia [(kg·m²)·10]:1.5
- Electrical Time Constant (ms):3.9
- Max. Speed (RPM):6000
- Instantaneous Max. Torque (Nm):7.2
- Torque Coefficient (Nm/A):0.54
- Weight (Kg):1.1
- Rated Current (A):4.8
- Max. Instantaneous Current (A):14.4
- Brake:Yes
